High energy density: 80~120Wh/kg
Cycle times ≥3000
Operating tem range: -20°C~60°C
Self-discharge rate @ RT ≤3% / year
High energy density: 80~120Wh/kg Cycle times ｌ3000 Operating tem. range: -20°C~60°C Self-discharge rate @ RT ｋ3% / year
High energy density: 80~120Wh/kg
Cycle times ≥3000
Operating tem range: -20°C~60°C
Self-discharge rate @ RT ≤3% / year
eCall on-board emergency call system
TCU/T-Box telematics control unit
Portable medical equipment
Smart metering
RF systems
Smart sensors
Security system
| Electrical characteristics | Nominal Capacity | 650mAh |
| Nominal Voltage | 3.7V | |
| Discharge Cut-off Voltage | 2.5V | |
| Charge Cut-off Voltage | 4.2V | |
| Cycle life（0.2C 100%DOD） | ≥800 | |
| Maximum Continuous Discharge Current | 650mA | |
| Maximum Pulse Discharge Current | 5000mA | |
| Maximum Charge Current | 650mA | |
| Internal Resistance(1kHz@RT) | ≤100mΩ | |
| Storage Environment（Recommended） | 25±3°C 65±20% RH | |
| Charge Temperature | 0℃~45℃ | |
| Discharge Temperature | -20℃~+60℃ | |
| Physical characteristics | Diameter(max) | 16.8mm |
| Height(max) | 34.0mm |
